Adapter 1/8 BSPP Male to 1/8 NPT Female

€ 3,95
Prijs per unit

Adapter for 1/8 BSP to 1/8 NPT. With 1/8 BSPP male to 1/8 NPT female.

Default delivery time: 2-4 Work Days

Product number: CPL-8224200012WNB

Order

Product description

Adapter for converting 1/8 BSP to 1/8 NPT.
With 1/8 BSPP male thread to 1/8 NPT female thread.

The outer thread is BSPP and conical.
The female thread is NPT and therefore conical.
The coupling housing is nickel-plated brass.

So you can screw the adapter into a 1/8 BSP input and screw in a 1/8 NPT coupling.

This adapter is easy to use.
Screw the adapter into a 1/8 BSPP input, then screw a 1/8 NPT coupling into the adaptor.
In this way you can convert a system with 'gas' and metric measurements to an American system.

Abbreviations:

NPT: National Pipe Thread, or National Pipe Taper. American thread, tapered.
BSP: British Standard Pipe, also called Gas Wire.
BSPP: British Standard Pipe Parallel, also called Gas Wire. (Parallel = straight)

More information about hose sizes and threads can be found here: About Thread

Close

Heb je een vraag over dit product?

You can contact us and ask your question via the options below.

0031 (0) 23 58 48 343

Product features

Eigenschappen Koppelingen

Shape Straight
Thread (A) 1/8 BSP-P (M)
Material Brass nickel plated
seal none
Max pressure 15 bar
Made in Italy
