Fiamm Jericho DIN | VOSS M16

€ 45,00

Fiamm Jericho. Truck horn with built-in 24v solenoid valve. With VOSS M16 pneumatic connection and DIN connector.

Default delivery time: 2-4 Work Days

Product number: FIA928050Z

Order

Product description

FIAMM Jericho DIN / VOSS M16
(FIA928050Z)


The FIAMM Jericho Air horn is a compact Truck air horn for professional use.
Air horn with built-in electronic valve for trucks and buses.
Fiamm supplies several variants of this type of horn, with both electrical and pneumatic connections differing.

This Jericho is equipped with a DIN connector and a VOSS M16 pneumatic connection.
Please note: An air tube cannot be connected directly to the pneumatic connection.
This model is used for Mercedes trucks.

Delivery:

1x Jericho Air horn
1x Connection Cable

Productinfo
Material PA66 , Steel
Measurements (HxWxL) 20cm x 12,5 cm x 9,5cm
Weight 390 gr.
Voltage 24v
Ampere 0,8 A
Air Pressure (Bar) 4-8 bar (amount of pressure influences dB's)
Soud Pressure (at 2m) 118 dB
Fiamm Code 928050Z
Connector Type: DIN (see download)
Air Connection VOSS M16 (Female)
EU-Registration 10 ECE
28 ECE
Made In Italy
HS Code 85123090


Attention:

1. For this horn you need air on board. This must produce at least 4bar - 8bar pressure.

2. For this horn you need a 24V electrical power supply on board.

Close
Downloads
JERICHO_928050.pdf
