6mm pin with 8mm PTC coupling
Plug-in coupling with PTC connection for 8 mm tube. This coupling can be plugged into another PTC connection with the 6mm pin. Suitable for Hadley horns with 6mm PTC connection.

Product number

CPL-5570500002

Default delivery time

2-4 Work Days

€ 2,75
Price per unit
Quantity:
Order


Do you have a question about this product?

Ask us your question

6mm pin with 8mm plug-in coupling


Suitable for Hadley horns with 6mm PTC connection.
Plug-in coupling for 8mm tube with pin.
With PTC connection for 8 mm tube and 6 mm pin to plug into another PTC connection.

The pin is additionally secured by the notch in another PTC coupling.
The housing of the coupling is plastic.

So you can insert the coupling into a 6mm PTC input and then connect a 8mm hose to it.

This coupling can be used simply by pushing the hose into the end of the coupling until it is firmly secured in place. The coupling and hose can be easily removed by pushing the ring back and pulling out the coupling or hose.

Total length: 38,5 mm
Pin length: 19 mm

Abbreviations :

PTC: Push To Connect.
8mm hose: Outside size of the hose is 8 millimeters.
Pin: End that can be inserted into a PTC coupling (just like a hose)


More information about hose sizes and threads can be found here: About Threads
Shape
Straight
Tube size
6mm
Tube size (B)
8mm
Tube connection
PTC (Push To Connect)
Material
Synthetic / Plastic
Max pressure
15 bar
Made in
Italy
